The Practical Guide to Distributed Training using PyTorch — Part 1: On a Single Node using torch.mul

Training deep learning models efficiently often requires leveraging multiple GPUs. PyTorch’s DistributedDataParallel (DDP) is the go-to solution for scalable multi-GPU training, but it comes with its own set of challenges.

In this in-depth guide, we’ll cover:
✅ Debugging the “Grad strides” warning
✅ When and why to use SyncBatchNorm
✅ Handling DistributedSampler vs. shuffle in DataLoader
✅ The role of init\_process\_group and how to configure it
✅ Why destroy\_process\_group is crucial
✅ Setting CUDA_VISIBLE_DEVICES correctly
✅ A full DDP training loop with best practices

Let’s dive in!

#1. “Grad strides do not match bucket view strides” — Causes & Fixes

Warning: Grad strides do not match bucket view strides. This may indicate grad was not created according to the gradient layout contract, or that the param’s strides changed since DDP was constructed. This is not an error, but may impair performance.
grad.sizes() = [1024, 1024, 1, 1], strides() = [1024, 1, 1024, 1024]
bucket_view.sizes() = [1024, 1024, 1, 1], strides() = [1024, 1, 1, 1] (function operator())

#What’s Happening?

When using DDP, PyTorch groups gradients into buckets for efficient communication (all-reduce operations). If the memory layout (strides) of gradients doesn’t match the bucket’s expected layout, PyTorch performs an unnecessary memory copy, slowing down training.

#Why Does This Happen?

• Non-contiguous tensors (e.g., after slicing, reshaping, permute, transpose, view or custom operations).
• Custom parameter initialization that disrupts memory alignment.
• Model architecture quirks (e.g., some RNNs or attention layers).

#How to Fix It?

1. Force contiguous tensors before DDP:

tensor = tensor.contiguous()  # Ensures memory alignment

2. Adjust bucket size (default: 25MB) to reduce fragmentation:

model = DDP(model, bucket_cap_mb=10)  # Smaller bucket size

3. Check model parameters for unintended non-contiguity:

for param in model.parameters():
    if not param.is_contiguous():
        param.data = param.data.contiguous()

#2. Why Use SyncBatchNorm in DDP?

#The Problem with Regular BatchNorm

• In DDP, each GPU computes local batch statistics (mean & variance).
• This leads to inconsistent normalization across GPUs, harming convergence.

#Solution: SyncBatchNorm

• Synchronizes batch statistics across all GPUs.
• Ensures consistent normalization, especially useful when:
  • Batch size per GPU is small.
  • Training vision models (CNNs) where BatchNorm is critical.

#How to Use It?

model = torch.nn.SyncBatchNorm.convert_sync_batchnorm(model)
model = DDP(model, device_ids=[rank])

A discussion on PyTorch forums regarding the usage of convert_sync_batchnorm before or after wrapping the model in DDP

Note:

• Adds communication overhead (slows training slightly).
• Only needed if BatchNorm is crucial for your model.

#3. DistributedSampler vs. shuffle in DataLoader — The Right Way

#The Problem

• DDP requires non-overlapping data splits across GPUs.
• Using shuffle=True in DataLoader breaks this partitioning.

#The Solution

• Always use DistributedSampler and disable shuffle in DataLoader:

sampler = DistributedSampler(dataset, shuffle=True)
# Controls shuffling globally
dataloader = DataLoader(dataset, batch_size=bs, sampler=sampler, shuffle=False)

The ‘shuffle’ argument in ‘DistributedSampler’ is set to True by default

Why?

• DistributedSampler ensures each GPU gets a unique subset.
• Setting shuffle=True in DataLoader would corrupt the data distribution.

#4. init\_process\_group — The Heart of DDP Setup

#Why Do We Need It?

• Initializes inter-process communication (IPC) for DDP.
• Defines the backend (nccl for GPU, gloo for CPU).

#Key Parameters

torch.distributed.init_process_group(backend="nccl",         # "nccl" for GPU), "gloo" (CPU/multi-node)
                                    init_method="env://",   # Uses `MASTER_ADDR` and `MASTER_PORT`
                                    world_size=world_size,  # Total # of processes (GPUs × nodes)

#When to Call It?

• After setting CUDA\_VISIBLE\_DEVICES (if restricting GPUs).
• Before wrapping the model with DDP.

#How to do the DDP setup?

from torch.distributed import init_process_group
def ddp_setup(rank: int, world_size: int):
    """
    Args:
    rank: Unique identifier of each process
    world_size: Total number of processes
    """
    os.environ[“MASTER_ADDR”] = “localhost”
    os.environ[“MASTER_PORT”] = “12355”
    torch.cuda.set_device(rank) # Setting device for the process
    init_process_group(backend="nccl", rank=rank, world_size=world_size)

#5. Why destroy\_process\_group is Essential

#The Problem

• Without cleanup, processes may hang or leave ports open.
• Can cause resource leaks and port conflicts in subsequent runs.

#The Solution

Always call:

torch.distributed.destroy_process_group()

Best Practice:

• Use a try-finally block to ensure cleanup:

try:
    train()
finally:
    destroy_process_group()

#Bonus: Setting CUDA\_VISIBLE\_DEVICES Correctly

To control which devices are used in DDP:

import os
os.environ["CUDA_VISIBLE_DEVICES"] = "0,1,2,3"  # Only use GPUs 0-3

If we want to use only two GPUs, then we can set

import os
os.environ["CUDA_VISIBLE_DEVICES"] = "2,3"  # Only use GPUs 2 and 3

In that case, ‘cuda:2’ will get assigned rank 0 and ‘cuda:3’ will get assigned rank 1.

#Why?

• Prevents PyTorch from seeing all GPUs on a node.
• Ensures each process gets a unique GPU (critical for DDP).

#Full DDP Training Loop Example

Here’s a complete, production-ready DDP training script:

import os
import torch
import torch.distributed as dist
import torch.multiprocessing as mp
from torch.nn.parallel import DistributedDataParallel as DDP
from torch.utils.data import DataLoader, DistributedSampler
from torchvision.datasets import CIFAR10
from torchvision.transforms import ToTensor
from torchvision.models import resnet18

def ddp_setup(rank, world_size):
    os.environ['MASTER_ADDR'] = 'localhost'
    os.environ['MASTER_PORT'] = '12355'
    torch.cuda.set_device(rank)
    dist.init_process_group("nccl", rank=rank, world_size=world_size)

def cleanup():
    dist.destroy_process_group()

def train(rank, world_size):
    # Setup DDP
    ddp_setup(rank, world_size)

    # Model + DDP
    model = resnet18().to(rank)
    model = torch.nn.SyncBatchNorm.convert_sync_batchnorm(model)
    model = DDP(model, device_ids=[rank])

    # Dataset + DistributedSampler
    dataset = CIFAR10(root='./data', train=True, transform=ToTensor(), download=True)
    sampler = DistributedSampler(dataset, num_replicas=world_size, rank=rank, shuffle=True)
    dataloader = DataLoader(dataset, batch_size=64, sampler=sampler, shuffle=False)

    # Optimizer
    optimizer = torch.optim.Adam(model.parameters(), lr=1e-3)
    criterion = torch.nn.CrossEntropyLoss()

    # Training loop
    for epoch in range(10):
        sampler.set_epoch(epoch)  # Ensures shuffling each epoch
        for batch_idx, (data, target) in enumerate(dataloader):
            data, target = data.to(rank), target.to(rank)
            optimizer.zero_grad()
            output = model(data)
            loss = criterion(output, target)
            loss.backward()
            optimizer.step()
            if batch_idx % 100 == 0 and rank == 0:  # Only print from master
                print(f"Epoch {epoch}, Batch {batch_idx}, Loss: {loss.item():.4f}")
     cleanup()

if __name__ == "__main__":
    os.environ['CUDA_VISIBLE_DEVICES'] = "0,1,2,3"
    world_size = torch.cuda.device_count()

    # If you want to use only a few particular GPU devices
    # os.environ['CUDA_VISIBLE_DEVICES'] = "2,3"
    # world_size = 2

    mp.spawn(train, args=(world_size,), nprocs=world_size, join=True)

#Key Takeaways from the Code

✔ setup() initializes DDP with init\_process\_group.
✔ DistributedSampler ensures correct data partitioning.
✔ sampler.set\_epoch(epoch) reshuffles data each epoch.
✔ cleanup() prevents resource leaks.

#Another Bonus: What does join=True do in torch.multiprocessing.spawn?

In torch.multiprocessing.spawn(), join=True means:

1. The main process will block (wait) until all spawned training processes complete.
2. If any process crashes, it ensures proper cleanup before continuing.

#Why It’s Important

1. Prevents Zombie Processes

• Without join=True, the main process might exit while child processes are running, leaving them orphaned.
• This can cause GPU memory leaks or hanging processes.

2. Ensures Clean Shutdown

• If one GPU process fails (e.g., OOM error), join=True ensures all other processes are terminated gracefully via destroy\_process\_group().

3. Safeguards Against Resource Leaks

• PyTorch’s NCCL backend requires coordinated process shutdown. join=True guarantees this.

#What Happens If You Set join=False?

• The main process would continue executing while training runs in the background.
• This is rarely what you want — your script might exit prematurely or cause undefined behaviour.

#Practical Example: Why join=True Matters

#Imagine this scenario without join=True:

1. Your training script starts 4 GPU processes.
2. The main Python process exits immediately (since it’s not waiting).
3. The 4 GPU processes keep running, but:

• Logs/outputs may not appear.
• Ctrl+C won’t kill them (zombie processes).
• You might need kill -9 to stop them.

#With join=True, the main process waits, and:

• You see all the logs.
• Ctrl+C propagates to all processes.
• Cleanup (like destroy\_process\_group()) runs reliably.

#Final Thoughts

DDP is powerful but nuanced. By following these best practices — gradient bucketing, SyncBatchNorm, proper DataLoader setup, and process management — you can scale PyTorch training efficiently across multiple GPUs.

Got questions? Drop them below! 🚀
