Comprehensive Guide to Overlaying Segmentation Masks in Python

Segmentation masks are fundamental in computer vision applications, from medical imaging to autonomous vehicles. Visualising these masks effectively helps in model evaluation and debugging. In this guide, we’ll explore two powerful methods for overlaying segmentation masks on images:

Transparent Overlay (using alpha blending with cv2.addWeighted)
Solid Overlay (direct pixel replacement)

We’ll implement both methods using OpenCV and NumPy, with detailed explanations and complete code examples.

#Understanding the Methods

#1. Transparent Overlay (Alpha Blending)

Alpha blending creates a semi-transparent overlay that allows the original image to show through the mask. This is particularly useful when you want to maintain context while visualising the segmentation.

Key Characteristics:

Adjustable transparency (alpha value between 0 and 1)
Smooth blending between the mask and the original image
Ideal for qualitative analysis where context matters

import cv2
import numpy as np
import os

def transparent_overlay(original_img, mask, color=(0, 255, 0), alpha=0.3):
    """
    Create a transparent overlay of a segmentation mask on an image.
          Args:
          original_img: Input image in BGR format
          mask: Binary mask (0 or 255)
          color: BGR tuple for mask color (default: green)
          alpha: Transparency level (0-1)
    Returns:
          Image with transparent overlay
    """
    # Ensure mask is binary and 3-channel
    if len(mask.shape) == 2:
        mask = (mask > 0).astype(np.uint8) * 255
        mask = cv2.cvtColor(mask, cv2.COLOR_GRAY2BGR)
    # Apply color to mask
    colored_mask = cv2.bitwise_and(mask, color)
    # Blend with original image
    return cv2.addWeighted(original_img, 1 - alpha, colored_mask, alpha, 0)

#2. Solid Overlay (Pixel Replacement)

This method completely replaces pixels in the mask region with a solid colour, providing high-contrast visualisation of the segmented areas.

Key Characteristics:

No transparency — mask areas are fully colored
Clear, unambiguous visualisation of segmentation boundaries
Best for binary segmentation tasks where precision is crucial

def solid_overlay(original_img, mask, color=(0, 0, 255)):
     """
      Create a solid color overlay of a segmentation mask on an image.
          Args:
          original_img: Input image in BGR format
          mask: Binary mask (0 or 255)
          color: BGR tuple for mask color (default: red)
      Returns:
          Image with solid overlay
      """
      # Convert mask to 3-channel if needed
      if len(mask.shape) == 2:
          mask = (mask > 0).astype(np.uint8)
          mask_3d = np.repeat(mask[:, :, np.newaxis], 3, axis=2)
      else:
          mask_3d = (mask > 0).astype(np.uint8)

      # Apply color where mask is active
      return np.where(mask_3d > 0, color, original_img)

#Implementation Details

#Prerequisites

Before running the code, ensure you have:

Python 3.x
OpenCV (pip install opencv-python)
NumPy (pip install numpy)

#Complete Code Implementation

def compare_masks(original_img, pred_mask, gt_mask, output_dir):
    """
    Compare predicted and ground truth masks using both overlay methods.
          Args:
          original_img: Base image
          pred_mask: Predicted segmentation mask
          gt_mask: Ground truth mask
          output_dir: Directory to save results
    """
    os.makedirs(output_dir, exist_ok=True)
    # Transparent overlays
    pred_trans = transparent_overlay(original_img, pred_mask, (0, 0, 255))
    gt_trans = transparent_overlay(original_img, gt_mask, (0, 255, 0))
    # Solid overlays
    pred_solid = solid_overlay(original_img, pred_mask, (0, 0, 255))
    gt_solid = solid_overlay(original_img, gt_mask, (0, 255, 0))
    # Overlap visualization
    overlap = cv2.bitwise_and((pred_mask > 0).astype(np.uint8),
                              (gt_mask > 0).astype(np.uint8)) * 255
    overlap_solid = solid_overlay(original_img, overlap, (0, 255, 255))

    # Save results
    cv2.imwrite(f"{output_dir}/predicted_transparent.png", pred_trans)
    cv2.imwrite(f"{output_dir}/ground_truth_transparent.png", gt_trans)
    cv2.imwrite(f"{output_dir}/predicted_solid.png", pred_solid)
    cv2.imwrite(f"{output_dir}/ground_truth_solid.png", gt_solid)
    cv2.imwrite(f"{output_dir}/overlap_solid.png", overlap_solid)

# Example usage

if __name__ == "__main__":
    # Load sample images
    original = cv2.imread("sample_image.jpg")
    pred_mask = cv2.imread("predicted_mask.png", cv2.IMREAD_GRAYSCALE)
    gt_mask = cv2.imread("ground_truth_mask.png", cv2.IMREAD_GRAYSCALE)
    # Process and save results
    compare_masks(original, pred_mask, gt_mask, "output_results")
    print("Processing complete. Results saved to 'output_results' folder.")

#Practical Applications

#Medical Imaging

In radiology, transparent overlays help doctors see tumours (marked in red) while maintaining visibility of surrounding anatomy. The adjustable alpha allows balancing between mask visibility and anatomical context.

#Autonomous Vehicles

For self-driving car systems, solid overlays clearly show detected pedestrians (red) and vehicles (blue) against the camera feed, ensuring quick visual verification of detection accuracy.

#Quality Control

In industrial inspection, solid overlays highlight defective regions on products, allowing quality control personnel to identify issues at a glance.

#Tips for Effective Visualisation

Colour Selection:

Use high-visibility colours (red, green, blue)
Maintain consistency across your team/project
Consider colourblind-friendly palettes

Transparency Adjustment:

Start with alpha=0.3 and adjust based on needs
Use a lower alpha for dense masks
Use a higher alpha for sparse masks

Performance Considerations:

For video processing, solid overlays are faster
Transparent overlays work well for static image analysis

#Troubleshooting Common Issues

Problem: Masks don’t align with the image

Solution: Verify both image and mask have the same dimensions and coordinate system

Problem: Colours appear incorrect

Solution: Remember OpenCV uses BGR order, not RGB

Problem: Overlay looks pixelated

Solution: Ensure masks are binary (0 or 255) before processing

#Conclusion

This guide has presented two essential techniques for visualising segmentation masks:

Transparent overlays for contextual analysis
Solid overlays for clear, unambiguous visualisation

The provided code offers a complete implementation you can adapt to your specific needs. By mastering both methods, you’ll be equipped to effectively visualise and analyse segmentation results across various computer vision applications.

For further enhancement, consider:

Adding contour outlines to your overlays
Implementing custom colourmaps for multi-class segmentation
Creating animation sequences to show mask evolution over time

Happy coding, and may your segmentation masks always be accurate
